Vortech V-2 H/D Ti Supercharger

The V-2 SQ model, with its highly advanced computer designed gears feature an optimized helical profile which allows for quieter operation while providing superior performance. All V-2 units feature a 3.6:1 internal step-up ratio and are direct bolt-on replacements for our V-1 units. The supercharger uses the quieter helical cut gears (3.61:1 ratio). The V-2 H/D Ti Supercharger is capable of up to 950HP on modified vehicles. Superior 75% peak efficiency. Ideal for latest generation of improved breathing, high-power street and strip engines.

Specifications:

• Internal Step-Up Ratio: 3.61:1
• Max Speed: 55,000 RPM
• Max Boost: 26 PSI
• Max Flow: 1,400 CFM
• Max Power: 950 HP
• Peak Efficiency: 75%

Dimensions:

• Discharge OD: 2.75"
• Inlet OD: 3.75"
• Discharge ID: 2.38"
• Inducer Diameter: 3.51"

The supercharger of choice for street/strip vehicles with modified engines

• Helical cut gear
• Available with straight or curved discharge and clockwise or counterclockwise rotation
• Part numbers below do not include drive pulley
• 8.75" Wide, 9.44" Tall, 5.52" Deep (not including input shaft)
