Forged Narrow Superlite 6R Big Brake Front Brake Kit (Hub)
FNSL6R billet Forged six-piston calipers with 13"-14" rotors deliver the ultimate combination for braking power and style in this group of kits engineered for traditional non-ABS spindles on American muscle cars and vintage rods. Built exclusively for 17" and larger wheels, SL6 kits enhance tire and suspension upgrades on all types of custom show and high performance dual-purpose street and track machines. A full range of options for caliper finishes and rotor designs are guaranteed to catch the eye of the most discriminating enthusiast while providing optimized brake performance for every individual application.
| Kit Summary |
|---|
| OE Hub Offset: |
+.68 |
| (Increase / Decrease Track Width) |
| Spindle Type: |
Drop Spindle Factory Disc Spindle |
| Mount Type: |
Radial |
| Caliper Type: |
6 - Red Powder Coat |
| Rotor Diameter: |
14 |
| Min Wheel Diameter Req'd*: |
18 |
| *This Brake Kit may fit 18-inch wheels. Please refer to the wheel clearance diagram to check to see if it will fit your specific wheel. |
THIS BRAKE KIT HAS AN HUB OFFSET OF: +.68
This Hub Offset will move the wheels inward or outward from the fender by this amount on each side of the vehicle
NOTES:
1. 14" Rotor
2. Kit fits 74-80 Pinto / Mustang II original disc brake spindles only.
Kit Components & Specifications
| Calipers |
|---|
| Left Hand - Part No: |
120-11781-RD |
| Right Hand - Part No: |
120-11780-RD |
| Type: |
Forged Narrow Superlite 6R |
| Finish Color: |
Red Powder Coat |
| Piston Count: |
6 |
| Piston Area (In²): |
4.04 |
| Piston Type: |
Stainless |
| Mount Type: |
Radial |
| Brake Pad Plate: |
7416 |
| Brake Pad Area (In²): |
8.2 |
| Brake Pad Volume (In³): |
3.8 |
| Pad Compound: |
BP-10 |
| Rotors |
|---|
| Left Hand - Part No: |
160-8403 |
| Right Hand - Part No: |
160-8402 |
| Type: |
GT 72 Curved Vane |
| Style: |
GT Slotted |
| Surface Finish: |
Plain |
| Material: |
Spec-37 Iron |
| Outside Diameter (in): |
14 |
| Width (in): |
1.1 |
| Vane Count: |
72 CV |
| Design Type: |
GT |
| Bedded: |
No |
| Dynamically Balanced: |
Yes |
| Rotor Hats |
|---|
| Hat - Part No: |
170-6994 |
| Type: |
Big Brake Hat - Flared Bell |
| Material: |
Aluminum |
| Finish Color: |
Black E-Coat |
| Hat Offset Dimension (in): |
1.88 |
| Bolt Circle 1: |
5 x 4.50 |
| Bolt Circle 2: |
5 x 4.75 |
| Bolt Circle 3: |
| Stud Diameter - BC 1: |
0.52 |
| Stud Diameter - BC 2: |
0.52 |
| Stud Diameter - BC 3: |
0 |
| Hubs |
|---|
| Hub - Part No: |
270-6989 |
| Type: |
Hub - Hat Mount |
| Material: |
Aluminum |
| Finish Color: |
Bare |
| Mount Style: |
Hat |
| Bolt Circle 1: |
5 x 4.50 |
| Bolt Circle 2: |
5 x 4.75 |
| Bolt Circle 3: |
| Stud Diameter - BC 1: |
1/2-20 |
| Stud Diameter - BC 2: |
1/2-20 |
| Stud Diameter - BC 3: |
Vehicle Fitments:
| Year |
Make |
Model |
Submodel |
| 1975 - 1978 |
Ford |
Mustang II |
Ghia, Mach 1, Base |
| 1975 - 1980 |
Ford |
Pinto |
Base |
| 1976 - 1980 |
Ford |
Pinto |
Squire, Pony |
| 1975 - 1980 |
Mercury |
Bobcat |
Base |
| 1976 |
Mercury |
Bobcat |
MPG Runabout, S Runabout |
| 1976 - 1980 |
Mercury |
Bobcat |
Runabout, Villager |
