Wilwood D52 Rear Caliper Kit - Black Pwdr 1.25 / 1.25" Piston,1.04" Rotor *Discontinued

D52 Rear Caliper Kit

Wilwood's D52 Rear Caliper Kit offers a matching rear replacement option for our front D52 calipers. It is a direct bolt-on 2-piston replacement for the factory original single piston calipers used on many custom application rears. With the added benefit of smaller rear piston sizing (2.46 sq-inches of area) not normally available in OEM calipers, for correct front and rear bias. Forged billet aluminum bodies, stainless steel pistons, and competition style high-temperature seals put an end to the rust, bore pitting, and seal failures that plague the OE caliper design. D52 calipers provide low-maintenance performance and a huge weight savings with high temperature reliability for the street and track. D52 calipers mount in the stock location over stock rotors, use the original style OE D52 brake pads and an OE 7/16-20 banjo bolt brake line mounting. Calipers can be used with most wheels that clear the OE calipers. Kits contain Wilwood’s hardened slide pins and BP-10 high friction pads. Matching rear calipers are also available for custom installations.

Specifications

Rear End Axle: OEM

Axle Offset: 0

Mount Type: Floating

Caliper Type: 2 - Black Powder Coat

Calipers

Left Hand - Part No: 120-10939-BK

Right Hand - Part No: 120-10939-BK

Type: D52

Finish Color: Black Powder Coat

Piston Count: 2

Piston 1 Bore (in): 1.25

Piston 2 Bore (in): 1.25

Piston Area (In²): 2.46

Piston Type: Stainless

Mount Type: Floating

Brake Pad Plate: D52

Brake Pad Area (In²): 10

Brake Pad Volume (In³): 3.9

Pad Compound: BP-10
