Swift Coilover Springs ID 2.5" 10" Length Barrel Type 80 lbs/inch
|
PART NUMBER
|
SPRING RATE | USABLE STROKE | MAX STROKE | MAX. LOAD |
| lbs/inch | inch | inch | lbs | |
| 100-250-080 B | 80 | 7.8 | 7.8 | 626 |
| 100-250-100 B | 100 | 7.6 | 7.6 | 765 |
| 100-250-115 B | 115 | 7.3 | 7.3 | 836 |
| 100-250-125 B | 125 | 7.3 | 7.3 | 917 |
| 100-250-135 B | 135 | 7.1 | 7.1 | 955 |
| 100-250-150 B | 150 | 6.8 | 8.2 | 1,152 |
| 100-250-160 B | 160 | 6.7 | 7.6 | 1,204 |
| 100-250-175 B | 175 | 6.5 | 7.6 | 1,325 |
| 100-250-185 B | 185 | 6.4 | 7.6 | 1,397 |
| 100-250-200 B | 200 | 6.4 | 7.4 | 1,480 |
| 100-250-225 B | 225 | 6.3 | 7.2 | 1,622 |
| 100-250-250 B | 250 | 6.1 | 7.1 | 1,780 |
| 100-250-275 B | 275 | 5.9 | 7.1 | 1,959 |
| 100-250-300 B | 300 | 5.8 | 7.0 | 2,103 |
| 100-250-325 B | 325 | 5.6 | 7.0 | 2,263 |
| 100-250-350 B | 350 | 5.6 | 6.8 | 2,384 |
| 100-250-375 B | 375 | 5.6 | 6.7 | 2,496 |
| 100-250-400 B | 400 | 5.5 | 6.6 | 2,629 |
| 100-250-425 B | 425 | 5.4 | 6.5 | 2,761 |
| 100-250-450 B | 450 | 5.3 | 6.4 | 2,889 |
| 100-250-475 B | 475 | 5.4 | 6.2 | 2,954 |
| 100-250-500 B | 500 | 5.3 | 6.1 | 3,051 |
| 100-250-525 B | 525 | 5.2 | 6.1 | 3,226 |
| 100-250-550 B | 550 | 5.2 | 6.0 | 3,312 |
| 100-250-575 B | 575 | 4.9 | 6.2 | 3,555 |
| 100-250-600 B | 600 | 5.0 | 5.9 | 3,565 |
Swift Coilover Springs ID 2.5" 10" Length Barrel Type
Sale price$121.00 USD
