Hella Mini ISO Relay Single

Mini ISO Relay Single

Features:

" 12 Volt

" SPDT / Form C

" Resistor Coil Suppression

" 40 Amp Continuous

" Mounting Bracket

Technical Data:

• Nominal Voltage: 12V
• Rated Continuous Load: N/O 40A | N/C 20A at 85° C
• Ambient Temperature: -40° C...+125° C
• Contact Form: 1 Form C / SPDT
• Contact Material: AgSnO2
• Operating / Drop out Voltage: d 8.0V /  e1.0V
• Max. Coil Voltage: 20V
• Coil Resistance: 73.8 Ohm ± 10% (incl. suppression component)
• Suppression: Resistor, 560 Ohm
• Mechanical Cycles: 10,000,000
• Operating / Releasing Time: d 10 ms / d 10 ms
• Dielectric Strength: e 1,000 VDC
• Max. Inrush Load: 150A
• Resistive Load / Switching Cycles: N/O 40A, N/C 20A, 100,000 cycles
• Inductive Load / Switching Cycles: N/O 20A, 100,000 cycles
• N/C 6A, 60,000 cycles
• Lamp Load (capacitive) / Switching Cycles: N/O 20A | N/C 10A, 100,000 cycles
• Vibration: 20 - 200 Hz, 5 g, no contact openings > 10  µs
• Mechanical Shock: Min. 10 g, 11 ms; no contact openings > 10  µs
• IP Rating Terminals: IP54 DIN IEC 60 529, 85, 86: ISO 8092 6.3 x 0.8, CuZn, gal Sn
• 30, 87, 87a: ISO 8092 6.3 x 0.8, CuZn
