Rancho RS9000XL Shock Absorber

The Rancho® RS9000"XL 9-position adjustable series delivers nine levels of performance to on- and off-road trucks, SUVs and Jeeps. Globally recognized as the first 9-position manually adjustable ride control series in the off-road market, the advanced RS9000XL series is ideal for on- and off-road use, towing and more. The adjustable damping enhances ride characteristics by counteracting the additional unsprung mass inherent in larger tire and wheel combinations.

Features:

" Large, 2.75-in. (70mm) tri-tube body - Increased fluid capacity to operate cooler

" Large, heavy-duty 18mm Nitro-Carb rod - Increases scuffing resistance & corrosion protection

" 9-position tuning technology - Allows for optimal performance in any environment

" 9-Position adjustment knob - Provides a clear understanding of tuning level

" Gas pressurization of shock - Minimizes air-to-oil mixture

" Graphite-filled, Fluon banded piston Provides smoother piston travel & greater responsiveness

" 1-1/4-in. Diameter Sintered Iron piston - Brings increased structural conformity

" Rebound Bumper - Helps control the rebound motion during harsh driving conditions

" Low-Friction, self-lubricating seal - Provides an extra layer of defense against dirt & debris

" Liquid metallic finish - Premium long lasting finish

" Protective boot - Added protection for the shock rod and oil seal

" Double-welded loops - Added strength and durability

Specifications

Compressed Length: 13.250

Extended Length: 20.920

Travel Length: 7.670

Lower Mounting Code: S4

Upper Mounting Code: S4

Vehicle Fitments:
