Dorman Pre-pressed Hub Assembly - Front

Pre-pressed Hub Assembly - Front

Our OE FIX offers a time-saving and cost-efficient solution for a complete hub assembly repair. The Dealers only repair option is to purchase components separately, requiring a specialized shop press and/or labor-intensive assembly prior to installation. Dorman offers one pre-assembled unit, consolidating all four components, ready for installation right out of the box. Additionally, this new design significantly cuts labor time by one to two hours.

• No special shop press tool required during installation saving one to two hours of labor
• Component pieces factory manufactured and assembled under rigorous quality control measures delivering higher quality consistency to meet or exceed the application needs
• Cost savings advantage to purchasing components separately
• Constructed of quality materials for high performance and durability

Product Specifications

• Anti Lock Brake Sensor Included: No
• Anti Lock Braking System: No
• Bolt Circle Diameter: 114.3 mm
• Brake Pilot Diameter: 64.1 mm
• Connector Quantity: 0
• Flange Bolt Hole Diameter: 10.7 mm
• Flange Bolt Hole Quantity: 4
• Flange Bolts Included: Yes
• Flange Diameter: 152.4 mm
• Flange Included: Yes
• Flange Offset: 47 mm
• Flange Shape: Rectangular
• Hub Pilot Diameter: 83 mm
• Package Contents: 1 Wheel Hub Assembly
• Package Quantity: 1
• Packaging Type: Box
• Selling Package Quantity UOM: Piece
• Spline Quantity: 28
• Wheel Pilot Diameter: 57.5 mm
• Wheel Stud Quantity: 5
• Wheel Studs Included: No

Application Summary: Acura Cl 1997, Honda Accord 1997-90

Vehicle Fitments:
