Moroso Oil Pan GM LS, Rear Sump, Swap, Fully Fabricated, Steel, Remote Oil
Moroso Oil Pan GM LS, Rear Sump, Swap, Fully Fabricated, Steel, Remote Oil
sku: 10N3Q | mpn: 20147
Regular price
$337.99
Regular price
$337.99
Sale price
$337.99
Shipping calculated at checkout.
Out of stock
Emissions
This is not an emissions item.
Quantity
Couldn't load pickup availability
- Ships Worldwide
- Easy Returns
- Fast Shipping
Fits: LS Engine Conversions that require a narrower Rear Sump (Check Measurements) for "Block Hugger" headers
Steel, Wet Sump, 5 Quart Capacity, 6" Deep, 8-1/4" Wide 8-3/8" Long
Engine Application: GM LS Series
Fits: Fits: LS Engine Conversions that require a narrower Rear Sump (Check Measurements) for "Block Hugger" headers
- Oil pan has a thick precision laser cut steel rail with a durable fabricated steel sump plated with a clear zinc ?nish
- Fabricated, durable steel construction is more adaptable to add ?ttings, change ?nishes and weighs less than cast aluminum construction
- Clears 4.25" stroke with most steel rods and can be used with Moroso No. 22491 Windage Tray
- Front of the oil pan is 1-7/8" deep to the beginning of the 6" Deep, 8-1/4" Wide, and 8-3/8" Long sump
- Anti-climb baffle
- Features a detachable, remote oil filter adapter constructed out of billet aluminum with two straight -10AN fittings
- Magnetic drain plug and uses a stock dipstick
