Moog Ball Joint:Upper,Chevy,GMC
Ball Joint
MOOG® Problem Solver® products incorporate proven design and engineering features for like-new steering, ease of installation and longer life. MOOG is the preferred steering and suspension brand of professional technicians and NASCAR crew chiefs.
- Hardened ball stud made of OE equivalent or better materials to withstand higher loads.
- Patent pending dust boot with encapsulated Belleville washer help control axial and radial movement.
- Powdered metal gusher bearing design enables grease to flow through bearing to stud for reduced friction and enhanced strength.
- Premium forged housing with increased cross section of up to 52% more material in key areas.
- Larger grease reservoir and easy-to-install pre-tapped grease fitting hole for improved maintenance.
- Greaseable socket reduces corrosion and wear by allowing new lubricant to flush contaminants.
Specifications
Ball Joint Specifications
Ball Joint Attachment Type: Bolt On
Mount Type: Bolt On
Greasable Design: Yes
Includes Grease Fitting/s: Yes
Includes Bolts: Yes
Includes Nuts: Yes
Includes Castle Nut: Yes
Includes Cotter Pin: Yes
Includes Cotter Pin Hole: Yes
Includes Hardware: Yes
Includes Bushings: No
Quantity of Bushings: 0
Includes Mount Plate: Yes
Mount Hole Quantity: 4
Includes Washers: Yes
Adjustable: No
Bolt Thread Size: 0.312-24
Boot Material: Neoprene
Heavy Duty: No
Height (Inch): 2.450
Length (Inch): 2.820
Stud Taper Per Foot: 0.047
Stud Thread: 0.500-20
Type of Suspension: Standard
Meets/Exceeds OE Manufacturer Specs: Yes
Vehicle Fitments:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1969 - 1970 | Chevrolet | Blazer | Base |
| 1963 - 1967 | Chevrolet | C10 Panel | Base |
| 1963 - 1970 | Chevrolet | C10 Pickup | Base |
| 1967 - 1970 | Chevrolet | C10 Suburban | Base |
| 1971 - 1972 | Chevrolet | G10 Van | Base, Sportvan |
| 1971 - 1972 | Chevrolet | G20 Van | Base, Sportvan |
| 1963 - 1967 | Chevrolet | P10 Series | Base |
| 1968 - 1970 | Chevrolet | P10 Van | Base |
| 1963 - 1966 | Chevrolet | Suburban | Base |
| 1967 - 1970 | GMC | C15/C1500 Pickup | Base |
| 1967 - 1970 | GMC | C15/C1500 Suburban | Base |
| 1971 | GMC | G15/G1500 Van | Base |
| 1971 - 1972 | GMC | G15/G1500 Van | Rally, Vandura |
| 1971 - 1972 | GMC | G25/G2500 Van | Base, Vandura, Rally |
| 1970 | GMC | Jimmy | Base |
| 1966 | GMC | P1000 | Base |
| 1967 - 1970 | GMC | P15/P1500 Van | Base |
| 1963 - 1966 | GMC | PB1000 Series | Base |
| 1966 | GMC | PB15 Series | Base |
| 1963 - 1965 | GMC | PB1500 Series | Base |
