Moog Tie Rod End:Greasable,Outer,Lincoln
Tie Rod End
MOOG® Problem Solver® products incorporate proven design and engineering features for like-new steering, ease of installation and longer life. MOOG is the preferred steering and suspension brand of professional technicians and NASCAR crew chiefs.
- Loose or worn chassis parts can lead to premature tire wear.
- Exclusive cover plate protects against contaminants leaking into the bearing surface.
- Greaseable socket design allows new lubricant to flush contaminants from the assembly, reducing corrosion and wear.
- Patent pending Sunoloy coated metal bearings provide smooth stud swing technicians and drivers prefer
- Patented cover plate design allows for tighter tolerances vs traditional designs for a more durable part.
- Powdered metal gusher bearing design enables grease to flow through bearing to stud for reduced friction and enhanced strength.
Tie Rods Specifications
Rod Thread: .687-18L
Configuration: STRAIGHT
Rod Type (Male / Female): MALE
Stud Diameter Dimension (top in.): 0.554
Stud Diameter Dimension (bottom in.): 0.626
Stud Thread: 1/2 - 20
End 1 Thread Diameter (in): 0.687
End 1 Threads Per Inch: 18
End 1 Thread Direction: L
End 2 Thread Diameter (in): 1/2
End 2 Threads Per Inch: 20
Vehicle Fitments:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1972 - 1974 | Ford | Country Sedan | Base |
| 1972 - 1974 | Ford | Country Squire | Base |
| 1972 - 1977 | Ford | Custom 500 | Base |
| 1975 - 1977 | Ford | Custom 500 | Ranch Wagon |
| 1972 - 1974 | Ford | Galaxie 500 | Base |
| 1972 - 1978 | Ford | LTD | Base |
| 1972 - 1976 | Ford | LTD | Brougham |
| 1975 - 1978 | Ford | LTD | Landau, Country Squire |
| 1977 - 1978 | Ford | LTD II | Brougham |
| 1979 | Ford | LTD II | Landau |
| 1977 - 1979 | Ford | LTD II | S, Base |
| 1977 | Ford | LTD II | Squire |
| 1973 - 1974 | Ford | Ranch Wagon | Base |
| 1972 - 1979 | Ford | Ranchero | GT, Squire, 500 |
| 1972 - 1979 | Ford | Thunderbird | Base |
| 1978 | Ford | Thunderbird | Diamond Jubilee |
| 1979 | Ford | Thunderbird | Heritage |
| 1978 - 1979 | Ford | Thunderbird | Town Landau |
| 1972 - 1976 | Ford | Torino | Base |
| 1975 - 1979 | Lincoln | Continental | Base |
| 1972 - 1976 | Lincoln | Mark IV | Base |
| 1977 - 1979 | Lincoln | Mark V | Base |
| 1977 | Mercury | Cougar | Villager, Brougham |
| 1974 - 1979 | Mercury | Cougar | XR-7, Base |
| 1972 - 1978 | Mercury | Marquis | Base, Brougham |
| 1975 - 1976 | Mercury | Marquis | Colony Park |
| 1972 - 1976 | Mercury | Montego | Base, MX, MX Brougham |
| 1975 | Mercury | Montego | Brougham |
| 1972 - 1973 | Mercury | Montego | GT |
| 1976 | Mercury | Montego | MX Villager |
| 1972 - 1975 | Mercury | Montego | Villager |
| 1972 - 1974 | Mercury | Monterey | Custom, Base |
Moog Tie Rod End:Greasable,Outer,Lincoln
Sale price$32.15 USD
