Moog Tie Rod End:Greasable,Outer,Ford
Tie Rod End
MOOG® Problem Solver® products incorporate proven design and engineering features for like-new steering, ease of installation and longer life. MOOG is the preferred steering and suspension brand of professional technicians and NASCAR crew chiefs.
- Loose or worn chassis parts can lead to premature tire wear.
- Exclusive cover plate protects against contaminants leaking into the bearing surface.
- Greaseable socket design allows new lubricant to flush contaminants from the assembly, reducing corrosion and wear.
- Patent pending Sunoloy coated metal bearings provide smooth stud swing technicians and drivers prefer
- Patented cover plate design allows for tighter tolerances vs traditional designs for a more durable part.
- Powdered metal gusher bearing design enables grease to flow through bearing to stud for reduced friction and enhanced strength.
Tie Rods Specifications
Greasable: Yes
Stud Center to End (in): 2.900
Rod Thread: 1-18
Configuration: OFFSET
Rod Type (Male / Female): FEMALE
Stud Diameter Dimension (top in.): 0.508
Stud Diameter Dimension (bottom in.): 0.624
Stud Thread: M10 X 1.50
Rack End Thread: M10 X 1.50
Dust Boot Included: Yes
End 1 Thread Diameter (mm): 14.0
End 1 Thread Pitch (MM): 2.0
End 1 Thread Direction: R
End 2 Thread Diameter (MM): 10.0
End 2 Thread Pitch (MM): 1.5
Vehicle Fitments:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2002 | Ford | Focus | Base, Manual |
| 2003 - 2004 | Ford | Focus | High, Mid |
| 2005 - 2006 | Ford | Focus | LX Austero, ZXW, ZX4, SE Tipico, ZX4 ST |
| 2000 - 2004 | Ford | Focus | SE, LX, ZTS |
| 2000 | Ford | Focus | Sony Limited Edition |
| 2002 - 2004 | Ford | Focus | SVT, ZTW |
| 2000 - 2006 | Ford | Focus | ZX3 |
| 2002 - 2006 | Ford | Focus | ZX5 |
Moog Tie Rod End:Greasable,Outer,Ford
Sale price$34.24 USD
