MOOG Chassis Products

Moog Tie Rod End

Moog Tie Rod End

sku: 14N9L | mpn: ES3581
$61.02
$61.02
Sale Sold out
Shipping calculated at checkout.

258 in stock

Emissions

This is not an emissions item.
  • Ships Worldwide
  • Easy Returns
  • Fast Shipping

MOOG® Problem Solver® products incorporate proven design and engineering features for like-new steering, ease of installation and longer life. MOOG is the preferred steering and suspension brand of professional technicians and NASCAR crew chiefs.

  • Loose or worn chassis parts can lead to premature tire wear
  • Exclusive cover plate protects against contaminants leaking into the bearing surface
  • Greaseable socket design allows new lubricant to flush contaminants from the assembly, reducing corrosion and wear
  • Patent pending Sunoloy coated metal bearings provide smooth stud swing technicians and drivers prefer
  • Patented cover plate design allows for tighter tolerances vs traditional designs for a more durable part
  • Powdered metal gusher bearing design enables grease to flow through bearing to stud for reduced friction and enhanced strength

Specifications

Tie Rods

Greaseable Yes
Stud Center to End (in) 2.37
Rod Thread M14 X 1.50
Configuration STRAIGHT
Rod Type (Male / Female) FEMALE
Stud Diameter Dimension (top in.) 0.498
Stud Diameter Dimension (bottom in.) 0.555
Stud Thread M10 X 1.25
Rack End Thread M10 X 1.25
Specification Image Reference OUTERTIEROD.tif
Dust Boot Included Yes
End 1 Thread Diameter (MM) 14.000
End 1 Thread Pitch (MM) 1.500
End 1 Thread Direction R
End 2 Thread Diameter (MM) 10.0
End 2 Thread Pitch (MM) 1.25


Vehicle Fitments:

Year Make Model Submodel
2001 - 2005 Acura EL Base
2001 - 2005 Honda Civic DX, HX, GX, EX, LX
2005 Honda Civic EX Special Edition, Reverb, LX Special Edition
2003 - 2005 Honda Civic Hybrid
2002 - 2005 Honda Civic Si
2002 - 2004 Honda Civic SiR
2004 - 2005 Honda Civic Value Package
2002 - 2003 Honda CR-V Base
2002 - 2006 Honda CR-V EX, LX
2005 - 2006 Honda CR-V SE, EX-L
View full details
