MOOG Chassis Products

Moog Tie Rod End:Outer, Ford

Moog Tie Rod End:Outer, Ford

sku: 14MG4 | mpn: ES3184RL
$60.94
$60.94 $60.94
Sale Sold out
Shipping calculated at checkout.

84 in stock

Emissions

This is not an emissions item.
  • Ships Worldwide
  • Easy Returns
  • Fast Shipping

Tie Rod End

MOOG® Problem Solver® products incorporate proven design and engineering features for like-new steering, ease of installation and longer life. MOOG is the preferred steering and suspension brand of professional technicians and NASCAR crew chiefs.

  • Loose or worn chassis parts can lead to premature tire wear.
  • Exclusive cover plate protects against contaminants leaking into the bearing surface.
  • Greaseable socket design allows new lubricant to flush contaminants from the assembly, reducing corrosion and wear.
  • Patent pending Sunoloy coated metal bearings provide smooth stud swing technicians and drivers prefer
  • Patented cover plate design allows for tighter tolerances vs traditional designs for a more durable part.
  • Powdered metal gusher bearing design enables grease to flow through bearing to stud for reduced friction and enhanced strength.

Tie Rods Specifications
Greasable: Yes
Stud Center to End (in): 5.450
Rod Thread: M14 X 1.50
Configuration: STRAIGHT
Rod Type (Male / Female): FEMALE
Stud Diameter Dimension (top in.): 0.554
Stud Diameter Dimension (bottom in.): 0.626
Stud Thread: M12 X 1.25
Rack End Thread: M12 X 1.25
Specification Image Reference: OUTERTIEROD.tif
Dust Boot Included: Yes
End 1 Thread Diameter (MM): 14.000
End 1 Thread Pitch (MM): 1.500
End 1 Thread Direction: R
End 2 Thread Diameter (MM): 12
End 2 Thread Pitch (MM): 1.25


Vehicle Fitments:

Year Make Model Submodel
1997 Ford Mustang Cobra
1994 Ford Mustang Convertible
1998 - 2003 Ford Mustang Equipado
2004 Ford Mustang GT Base, GT Equipado
2001 Ford Mustang GT Bullitt
1994 - 2004 Ford Mustang GT, Base, SVT Cobra
1995 Ford Mustang GTS
1996 - 1997 Ford Mustang High
2003 - 2004 Ford Mustang Mach 1
1998 Ford Mustang Semi-Equipado
2003 Ford Mustang SVT Cobra 10th Anniversary
1995 - 2000 Ford Mustang SVT Cobra R
View full details
