Moog Tie Rod End:Greasable,Outer,Chevy/Ford,GMC
Tie Rod End
MOOG® Problem Solver® products incorporate proven design and engineering features for like-new steering, ease of installation and longer life. MOOG is the preferred steering and suspension brand of professional technicians and NASCAR crew chiefs.
- Loose or worn chassis parts can lead to premature tire wear.
- Exclusive cover plate protects against contaminants leaking into the bearing surface.
- Greaseable socket design allows new lubricant to flush contaminants from the assembly, reducing corrosion and wear.
- Patent pending Sunoloy coated metal bearings provide smooth stud swing technicians and drivers prefer
- Patented cover plate design allows for tighter tolerances vs traditional designs for a more durable part.
- Powdered metal gusher bearing design enables grease to flow through bearing to stud for reduced friction and enhanced strength.
Tie Rods Specifications
Greasable: Yes
Stud Center to End (in): 3.500
Rod Thread: 3/4" - 16"
Rod Type (Male / Female): MALE
Configuration: STRAIGHT
Stud Diameter Dimension (top in.): 0.612
Stud Diameter Dimension (bottom in.): 0.705
Stud Thread: 9/16" - 18"
Rack End Thread: 9/16" - 18"
Dust Boot Included: Yes
End 1 Thread Diameter (IN): 3/4
End 1 Thread Direction: L
End 1 Threads Per Inch: 16
End 2 Thread Diameter (IN): 9/16
End 2 Threads Per Inch: 18
Vehicle Fitments:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1964 - 1966 | Chevrolet | K10 Pickup | Base |
| 1961 - 1966 | Chevrolet | K20 Pickup | Base |
| 1964 - 1966 | Chevrolet | Suburban | Base |
| 1961 - 1965 | Ford | F-100 | Base |
| 1961 - 1966 | Ford | F-250 | Base |
| 1953 - 1966 | Ford | F-350 | Base |
| 1948 - 1952 | Ford | F4 | Base |
| 1953 - 1976 | Ford | P-350 | Base |
| 1975 - 1976 | Ford | P-350 | Custom |
| 1975 - 1976 | Ford | P-400 | Custom, Base |
| 1975 - 1977 | Ford | P-500 | Custom, Base |
| 1966 | GMC | 1000 | Base |
| 1963 - 1965 | GMC | 1000 Series | Base |
| 1966 | GMC | 1500 | Base |
| 1963 - 1965 | GMC | 1500 Series | Base |
| 1966 | GMC | 2500 | Base |
| 1963 - 1965 | GMC | 2500 Series | Base |
| 1965 - 1966 | GMC | I1500 | Base |
| 1966 | GMC | K1000 | Base |
| 1966 | GMC | K1000 Pickup | Base |
| 1966 | GMC | K15/K1500 Pickup | Base |
| 1963 - 1966 | GMC | Suburban | Base |
| 1966 | International | 1200A | Travelall Custom, Base |
| 1967 | International | 1200B | Travelall Custom, Base |
| 1968 | International | 1200C | Base |
| 1957 - 1958 | International | A120 | Base |
| 1957 - 1958 | International | A122 | Base |
| 1961 - 1962 | International | C120 | Base |
| 1963 - 1964 | International | C1200 | Base |
| 1961 - 1962 | International | C122 | Base |
| 1956 - 1957 | International | S120 | Base |
| 1956 - 1957 | International | S122 | Base |
Moog Tie Rod End:Greasable,Outer,Chevy/Ford,GMC
Sale price$28.06 USD
Regular price$58.99 USD
