Moog Tie Rod End, Greasable, Outer, Jeep,
Moog Tie Rod End, Greasable, Outer, Jeep,
sku: 14NGP | mpn: DS1237
Regular price
$179.98
Regular price
$240.04
Sale price
$179.98
Shipping calculated at checkout.
Low stock: 3 left
Emissions
This is not an emissions item.
Quantity
Couldn't load pickup availability
- Ships Worldwide
- Easy Returns
- Fast Shipping
| Rod Thread | M22-1.5 RH |
| Stud Diameter Dimension (Top in) | 0.553 |
| Stud Diameter Dimension (bottom in.) | 0.625 |
| Length (in) | 45.750 |
| End 1 Thread Diameter (MM) | 22.000 |
| End 1 Threads Per Inch (MM) | 1.500 |
| End 1 Thread Direction | R |
| Tapered Hole Quantity | 2 |
- Loose or worn chassis parts can lead to premature tire wear
- Exclusive cover plate protects against contaminants leaking into the bearing surface
- Greaseable socket design allows new lubricant to flush contaminants from the assembly, reducing corrosion and wear
- Patent pending Sunoloy coated metal bearings provide smooth stud swing technicians and drivers prefer
- Patented cover plate design allows for tighter tolerances vs traditional designs for a more durable part
- Powdered metal gusher bearing design enables grease to flow through bearing to stud for reduced friction and enhanced strength
Vehicle Fitments:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 1991 - 1995 | Jeep | Wrangler | Base, Sahara |
| 1991 - 1992 | Jeep | Wrangler | Islander |
| 1991 - 1994 | Jeep | Wrangler | Renegade, S |
| 1995 | Jeep | Wrangler | Rio Grande |
| 1994 - 1995 | Jeep | Wrangler | SE |
