Moog Tie Rod End, Greasable, Outer, Jeep,
SKU: 14NGP | MPN:
DS1237
| Rod Thread |
M22-1.5 RH |
| Stud Diameter Dimension (Top in) |
0.553 |
| Stud Diameter Dimension (bottom in.) |
0.625 |
| Length (in) |
45.750 |
| End 1 Thread Diameter (MM) |
22.000 |
| End 1 Threads Per Inch (MM) |
1.500 |
| End 1 Thread Direction |
R |
| Tapered Hole Quantity |
2 |
- Loose or worn chassis parts can lead to premature tire wear
- Exclusive cover plate protects against contaminants leaking into the bearing surface
- Greaseable socket design allows new lubricant to flush contaminants from the assembly, reducing corrosion and wear
- Patent pending Sunoloy coated metal bearings provide smooth stud swing technicians and drivers prefer
- Patented cover plate design allows for tighter tolerances vs traditional designs for a more durable part
- Powdered metal gusher bearing design enables grease to flow through bearing to stud for reduced friction and enhanced strength
Vehicle Fitments:
| Year |
Make |
Model |
Submodel |
| 1991 - 1995 |
Jeep |
Wrangler |
Base, Sahara |
| 1991 - 1992 |
Jeep |
Wrangler |
Islander |
| 1991 - 1994 |
Jeep |
Wrangler |
Renegade, S |
| 1995 |
Jeep |
Wrangler |
Rio Grande |
| 1994 - 1995 |
Jeep |
Wrangler |
SE |
