Moog Hub Assembly:Wheel Hub and Bearing Assembly,Rear,Ford,Lincoln,Mazda
Hub Assembly
MOOG® hub assemblies are performance proven, quality tested and are available for a broad range of foreign and domestic vehicles. Their application-specific design enhancements provide longer life, smoother operation and optimum ABS performance.
- Wheel Stud Bolts: Wheel studs feature a protective coating that helps prevent rust and corrosion, allowing easier removal and proper torquing of the wheel nut.
- Precision Matched Components: Rigorously controlled manufacturing processes ensure exact matching of bearing raceways and rolling elements to consistently deliver superior performance and minimize noise and vibration.
- Engineered to overcome problems and deliver smooth, reliable performance.
- MOOG® hub assemblies are performance proven, quality tested and are available for a broad range of foreign and domestic vehicles.
Specifications
Hub Assemblies
Bolt Quantity: 4
Flange Diameter (A): 139.8
Bolt Circle Diameter (B): 4.500
Bolt Circle Diameter Metric (B): 114.3
Bolt Size (C): 1/2-20
Wheel Pilot Diameter (D): 70.5
Brake Pilot Diameter (E): 71.9
Flange Offset (F): 63.0
Hub Pilot Diameter (G): 78.0
Bolt Hole MET (I): M14x2
Bolt Hole Quantity: 5
Number of Splines: 28
Flange Shape (K): MODIFIED
ABS Sensor: Encoder
Location: Rear Wheel
Vehicle Fitments:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2008 - 2010 | Ford | Edge | Limited |
| 2007 - 2010 | Ford | Edge | SE, SEL |
| 2007 | Ford | Edge | SEL Plus |
| 2009 - 2010 | Ford | Edge | Sport |
| 2007 - 2010 | Lincoln | MKX | Premium, Base |
Moog Hub Assembly:Wheel Hub and Bearing Assembly,Rear,Ford,Lincoln,Mazda
Sale price$147.43 USD
Regular price$174.34 USD
