Moog Hub Assembly:Wheel Hub and Bearing Assembly,Cadillac,Chevy
Hub Assembly
MOOG® hub assemblies are performance proven, quality tested and are available for a broad range of foreign and domestic vehicles. Their application-specific design enhancements provide longer life, smoother operation and optimum ABS performance.
- Innovative roll form design ensures consistent and optimal preload.
- Wheel Stud Bolts: Wheel studs feature a protective coating that helps prevent rust and corrosion, allowing easier removal and proper torquing of the wheel nut.
- MOOG® Abrasion-Resistant ABS Cord: Manufactured from a blended material that provides superior ABS protection, increases abrasion resistance and protects against adverse conditions.
- Precision Matched Components: Rigorously controlled manufacturing processes ensure exact matching of bearing raceways and rolling elements to consistently deliver superior performance and minimize noise and vibration.
- Engineered to overcome problems and deliver smooth, reliable performance.
Specifications
Hub Assemblies
Bolt Quantity: 3
Flange Diameter (A): 145.5
Bolt Circle Diameter (B): 4.750
Bolt Circle Diameter Metric (B): 120.7
Bolt Size (C): M12X1.5
Wheel Pilot Diameter (D): 70.1
Brake Pilot Diameter (E): 70.6
Flange Offset (F): 42.1
Hub Pilot Diameter (G): 91.3
Bolt Hole MET (I): M12X1.75
Bolt Hole Quantity: 5
Number of Splines: 30
Flange Shape (K): TRIANGULAR
ABS Sensor: Cable
Location: Rear Wheel
Vehicle Fitments:
| Year | Make | Model | Submodel |
|---|---|---|---|
| 2004 - 2008 | Cadillac | XLR | Base |
| 2008 | Cadillac | XLR | Platinum |
| 2006 - 2008 | Cadillac | XLR | V |
| 2008 | Chevrolet | Corvette | 427 Limited Edition Z06 |
| 2003 | Chevrolet | Corvette | 50th Anniversary Edition, 50th Anniversary Edition Pace Car |
| 1997 - 2008 | Chevrolet | Corvette | Base |
| 1998 | Chevrolet | Corvette | Indianapolis 500 Pace Car |
| 2001 - 2008 | Chevrolet | Corvette | Z06 |
Moog Hub Assembly:Wheel Hub and Bearing Assembly,Cadillac,Chevy
Sale price$190.25 USD
