Manley Performance Rod-14088 With ARP 2000

Manley steel H-beam connecting rods are made from forged 4340 steel alloy. They're packed full of performance features, such as a compact uniform-grain structure for ultimate strength, full machining, stress relieving, and magnafluxing. The wrist pin and big end bores are honed to a +/-.0002 in. tolerance, and the wrist pins get a bronze alloy bushing. These units include cap screw ARP 8740 alloy rod bolts, and each rod set is weight-matched to within 2 grams.

• Quantity:Sold as a set of 8.
• Connecting Rod Length Center to Center (in):6.200 in.
• Connecting Rod Beam Style:H-beam
• Connecting Rod Material:Forged 4340 steel
• Connecting Rod Finish:Shot-peened and tumbled
• Wrist Pin Style:Floating
• Clearanced for Stroker:Yes
• Cap Retention Style:Cap screw
• Connecting Rod Bolt Brand:ARP
• Connecting Rod Bolt Diameter:7/16 in.
• Connecting Rod Bolt Material:ARP2000 alloy
• Fastener Yield Strength (psi):220,000 psi
• Connecting Rod Bolt Head Style:12-point
• Approximate Connecting Rod Weight (g):665
• Rod Journal Diameter (in):2.100 in.
• Big End Bore Diameter (in):2.2520 in.
• Pin End Bore Diameter:0.928 in.
• Big End Width (in):0.933 in.
• Pin End Width (in):1.000 in.
• Advertised Horsepower Rating:775 hp
• Weight Matched Set:Yes
• Remanufactured:No
• Magnafluxed:Yes
