Intermotor Engine Cooling Fan Switch TS-329

Engine Cooling Fan Switch. (TS-329) by Intermotor
Robust design and high grade materials meet the stringent demands of today's service professional. In design, we specify custom wax formulations that will expand when heated, activate a snap action electrical contact and transfer the electrical signal to the fan controller. In manufacturing, we custom form the wax pellets for different temperature range specifications. All units are calibrated & tested to confirm switch actuation at their specified temperature. The switch is designed using a formed bimetallic contact arm. The bimetal contact movement is achieved using the different expansion rates of two metals fused together. This is a creep action device, provides precise performance. In production, all thermal switches are factory-calibrated to make electrical contact at the specified lower-temperature set point. As a global manufacturer of original equipment ignition products, we maintain complete quality control throughout the manufacturing process from componentry to finished product.
Vehicle Fitments:
Year | Make | Model | Submodel |
---|---|---|---|
1998 - 1999 | Lexus | GS300 | Base |
1998 - 2000 | Lexus | GS400 | Base |
1995 - 2000 | Lexus | LS400 | Base |
1992 - 1994 | Toyota | Camry | Base |
1997 - 2001 | Toyota | Camry | CE |
1992 | Toyota | Camry | DLX |
1993 - 1996 | Toyota | Camry | DX |
1992 - 2001 | Toyota | Camry | LE, XLE |
1992 - 1996 | Toyota | Camry | SE |
1990 - 1992 | Toyota | Celica | All Trac |
1994 - 1995 | Toyota | Celica | Base |
1990 - 1999 | Toyota | Celica | GT |
1990 - 1993 | Toyota | Celica | GTS |
1993 | Toyota | Celica | GTS All Trac |
1990 - 1997 | Toyota | Celica | ST |
1992 - 1994 | Toyota | MR2 | Base, Turbo |
1992 - 1996 | Toyota | Paseo | Base |
1996 - 2000 | Toyota | RAV4 | Base |
1999 - 2001 | Toyota | Solara | SLE, SE |
1990 | Toyota | Tercel | Base, EZ, DX |
1991 - 1993 | Toyota | Tercel | DLX, LE |
1990 - 1993 | Toyota | Tercel | S, STD |
