MOOG Hub Assemblies

Moog Hub Assembly

Moog Hub Assembly

sku: 1EFN9 | mpn: 513017-K
$91.01
$96.41 $91.01
Sale Sold out
Shipping calculated at checkout.

Out of stock

Emissions

This is not an emissions item.
  • Ships Worldwide
  • Easy Returns
  • Fast Shipping
MOOG hub assemblies are performance proven, quality tested and are available for a broad range of foreign and domestic vehicles. Their application-specific design enhancements provide longer life, smoother operation and optimum ABS performance.
 Wheel Stud Bolts: Wheel studs feature a protective coating that helps prevent rust and corrosion, allowing easier removal and proper torquing of the wheel nut.
 Precision Matched Components: Rigorously controlled manufacturing processes ensure exact matching of bearing raceways and rolling elements to consistently deliver superior performance and minimize noise and vibration.
 Engineered to overcome problems and deliver smooth, reliable performance.
 MOOG hub assemblies are performance proven, quality tested and are available for a broad range of foreign and domestic vehicles.

Specifications

Hub Assemblies
Bolt Quantity:
3
Flange Diameter (A):
125.0
Bolt Circle Diameter (B):
3.937
Bolt Circle Diameter Metric (B):
100.0
Bolt Size (C):
M12X1.5
Wheel Pilot Diameter (D):
57.0
Brake Pilot Diameter (E):
58.3
Flange Offset (F):
44.3
Hub Pilot Diameter (G):
73.5
Bolt Hole MET (I):
13
Bolt Hole Quantity:
5
Number of Splines:
33
Flange Shape (K):
MODIFIED TRIANGLE
ABS Sensor:
No
Location:
Front Wheel
Bearing OD (Inch):
9.842
Bearing Width (Inch):
3.819
Inner Race Radius (Inch):
0.140
Inner Race Width (Inch):
3.819
Outter Race OD (Inch):
4.921
Outter Race Width (Inch):
3.819
Bearing OD (mm):
125.0
Bearing Width (mm):
97.0
Inner Race Radius (mm):
3.6
Inner Race Width (mm):
97.0
Outter Race OD (mm):
125.0
Outter Race Width (mm):
97.0

PASSENGER CAR & LIGHT TRUCK
Make
Model
Year Range
Position
Drive Wheel
Veh. Qty.
Engine Base
Engine VIN
Engine Desg.
Buick Skyhawk 1989-1984 Front 2
Buick Skylark 1998-1986 Front 2
Buick Somerset 1987-1986 Front 2
Buick Somerset Regal 1985 Front 2
Cadillac Cimarron 1988-1984 Front 2
Chevrolet Beretta 1996-1987 Front 2
Chevrolet Cavalier 2005-1984 Front 2
Chevrolet Corsica 1996-1987 Front 2
Oldsmobile Achieva 1998-1992 Front 2
Oldsmobile Calais 1987-1985 Front 2
Oldsmobile Cutlass Calais 1991-1988 Front 2
Oldsmobile Firenza 1988-1984 Front 2
Pontiac Grand Am 1998-1985 Front 2
Pontiac J2000 Sunbird 1985-1984 Front 2
Pontiac Sunbird 1994-1986 Front 2
Pontiac Sunfire 2005-1995 Front 2
Pontiac Tempest 1991-1987 Front 2


Vehicle Fitments:

Year Make Model Submodel
1984 - 1989 Buick Skyhawk Custom
1988 - 1989 Buick Skyhawk SE
1986 - 1987 Buick Skyhawk Sport
1984 - 1987 Buick Skyhawk T-Type, Limited
1986 - 1998 Buick Skylark Custom
1990 - 1997 Buick Skylark Gran Sport
1986 - 1997 Buick Skylark Limited
1990 - 1991 Buick Skylark Luxury Edition, Base
1996 Buick Skylark Olympic Gold Edition
1986 - 1987 Buick Somerset Limited, Custom
1986 Buick Somerset T-Type
1985 Buick Somerset Regal Limited, Base
1984 - 1988 Cadillac Cimarron Base
1984 - 1986 Cadillac Cimarron d'Oro
1987 - 1996 Chevrolet Beretta Base
1989 - 1993 Chevrolet Beretta GT
1990 - 1993 Chevrolet Beretta GTZ
1990 Chevrolet Beretta Indianapolis 500 Pace Car
1994 - 1996 Chevrolet Beretta Z26
1984 - 2005 Chevrolet Cavalier Base
1984 - 1986 Chevrolet Cavalier CL
1984 - 1987 Chevrolet Cavalier CS
1995 - 2005 Chevrolet Cavalier LS
2002 - 2005 Chevrolet Cavalier LS Sport
1984 Chevrolet Cavalier Olympic
1986 - 1999 Chevrolet Cavalier RS
1984 - 1985 Chevrolet Cavalier Type-10
1988 - 1994 Chevrolet Cavalier VL
1986 - 2002 Chevrolet Cavalier Z24
1987 - 1996 Chevrolet Corsica Base
1987 - 1993 Chevrolet Corsica LT
1989 - 1992 Chevrolet Corsica LTZ
1992 - 1998 Oldsmobile Achieva S
1992 - 1993 Oldsmobile Achieva SCX
1992 - 1997 Oldsmobile Achieva SL, SC
1985 Oldsmobile Calais 500
1986 Oldsmobile Calais ES
1986 - 1987 Oldsmobile Calais GT
1985 - 1987 Oldsmobile Calais Supreme, Base
1989 - 1991 Oldsmobile Cutlass Calais S
1988 - 1991 Oldsmobile Cutlass Calais SL, Base, International, GT
1984 - 1988 Oldsmobile Firenza Base, Cruiser
1984 - 1985 Oldsmobile Firenza Brougham LX, Cruiser SX, ES, Brougham SX
1984 - 1986 Oldsmobile Firenza Cruiser LX
1986 - 1987 Oldsmobile Firenza LC
1984 - 1987 Oldsmobile Firenza LX, GT, S
1984 Oldsmobile Firenza SX
1985 - 1988 Pontiac Grand Am Base
1992 - 1998 Pontiac Grand Am GT
1985 - 1991 Pontiac Grand Am LE
1986 - 1998 Pontiac Grand Am SE
1991 Pontiac Grand Am Value Leader
1984 - 1985 Pontiac J2000 Sunbird LE, SE, Base
1986 - 1988 Pontiac Sunbird Base
1989 - 1994 Pontiac Sunbird LE
1992 - 1993 Pontiac Sunbird LE Value Leader
1986 - 1994 Pontiac Sunbird SE, GT
1991 Pontiac Sunbird Value Leader
1997 - 2005 Pontiac Sunfire Base
1995 - 2003 Pontiac Sunfire GT
2000 Pontiac Sunfire GT Milenio
1995 - 2004 Pontiac Sunfire SE
1987 - 1991 Pontiac Tempest Base
1991 Pontiac Tempest LE
