Moog Hub Assembly

SKU: 1EFLX | MPN:  512217
In stock
Sale price$144.41 USD

MOOG hub assemblies are performance proven, quality tested and are available for a broad range of foreign and domestic vehicles. Their application-specific design enhancements provide longer life, smoother operation and optimum ABS performance.
 Innovative roll form design ensures consistent and optimal preload.
 Precision Matched Components: Rigorously controlled manufacturing processes ensure exact matching of bearing raceways and rolling elements to consistently deliver superior performance and minimize noise and vibration.
 Engineered to overcome problems and deliver smooth, reliable performance.
 MOOG hub assemblies are performance proven, quality tested and are available for a broad range of foreign and domestic vehicles.
Specifications
Hub Assemblies
Bolt Quantity: 4
Flange Diameter (A): 135.0
Bolt Circle Diameter (B): 3.940
Bolt Circle Diameter Metric (B): 100.0
Bolt Size (C): M12X1.5
Wheel Pilot Diameter (D): 54.0
Brake Pilot Diameter (E): 55.0
Flange Offset (F): 54.5
Hub Pilot Diameter (G): 74.0
Bolt Hole MET (I): M10x1.25
Bolt Hole Quantity: 5
Flange Shape (K): RECTANGULAR
ABS Sensor: Sensor
Location: Rear Wheel

PASSENGER CAR & LIGHT TRUCK
Make
Model
Year Range
Position
Drive Wheel
Veh. Qty.
Engine Base
Engine VIN
Engine Desg.
Pontiac Vibe 2008-2003 Rear FWD 2
Toyota Corolla 2008-2003 Rear 2
Toyota Matrix 2008-2003 Rear FWD 2
Toyota Prius 2009-2004 Rear 2


Vehicle Fitments:

Year Make Model Submodel
2003 - 2008 Pontiac Vibe Base
2003 - 2006 Pontiac Vibe GT
2003 - 2008 Toyota Corolla CE, LE, S
2008 Toyota Corolla Sport
2005 - 2006 Toyota Corolla XRS
2003 - 2008 Toyota Matrix Base, XR, XRS
2004 - 2009 Toyota Prius Base
2007 - 2009 Toyota Prius Touring
