HPS Performance Stainless Steel Worm Gear Liner Clamp 1-5/16" - 2-1/4", 33mm-57mm / 10pcs

Key Features
Effective Diameter Range: 1-5/16" - 2-1/4" (33mm-57mm).
100% Stainless Steel.
Sold in Box of 10.
Four piece heavy duty industrial grade quad-lock design, inner protective liner prevents the damage of the hose.
Maximum Torque Spec: 35 in lbs, Exceeds all SAE requirements.
1/2" band , 5/16" (8mm) slotted hex screw.

HPS 100% stainless steel worm gear hose clamps SAE # 28 10pcs pack 1-5/16" - 2-1/4" (33mm-57mm) feature a 4-piece heavy duty industrial grade quad-lock design that allows more tightening torque compared to other aftermarket clamps. These HPS liner hose clamps feature an inner protective sleeve which can prevent the damage of the silicone hose. This clamp delivers maximum protection while concentrically sealing soft hoses. The HPS stainless steel worm gear hose clamp is ideal for aircraft use, heavy-duty industrial applications as well as outdoor, fresh water and mildly corrosive services. This product is composed of a stainless steel band, screw, saddle and housing. Technical specification: SAE #28. 1/2 inch band. 5/16 inch (8mm) slotted hex screw. Effective diameter range: 1-5/16" - 2-1/4" (33mm-57mm). Maximum torque specification: 35 in-lbs. Exceeds all SAE requirements. REMARK: Sold in box of 10.

Key Features
Effective Diameter Range: 1-9/16" - 2-1/2" (40mm-64mm)
100% Stainless Steel
Sold in Box of 10
Four piece heavy duty industrial grade quad-lock design, inner protective liner prevents the damage of the hose
Maximum Torque Spec: 35 in lbs, Exceeds all SAE requirements
1/2" band , 5/16" (8mm) slotted hex screw

HPS 100% Stainless Steel Worm Gear Liner Hose Clamps SAE # 32 10pcs pack 1-9/16" - 2-1/2" (40mm-64mm) feature four piece heavy duty industrial grade quad-lock design allows more tightening torque compare to other aftermarket clamps. These HPS liner hose clamps features an inner protective sleeve which can prevent the damage of the silicone hose and delivers maximum protection and concentric seal to soft hoses. The HPS stainless steel worm gear liner hose clamps are ideal for aircraft, heavy-duty industrial applications as well as outdoor, fresh water and mildly corrosive applications. This HPS minature stainless steel clamp consist of stainless steel band, screw, saddle and housing. Technical Specification: SAE # 32. 100% Stainless Steel. 1/2 inch band. 5/16 inch (8mm) slotted hex screw. Four piece heavy duty industrial grade quad-lock design. Inner protective liner prevents the damage of the hose. Effective Diameter Range: 1-9/16" - 2-1/2" (40mm-64mm). Maximum Torque Spec: 35 in lbs. Exceeds all SAE requirements. REMARK: Sold in box of 10.

Key Features
Effective Diameter Range: 3-5/16" - 4-1/4" (84mm-108mm)
100% Stainless Steel
Sold in Box of 10
Four piece heavy duty industrial grade quad-lock design, inner protective liner prevents the damage of the hose
Maximum Torque Spec: 35 in lbs, Exceeds all SAE requirements
1/2" band , 5/16" (8mm) slotted hex screw

HPS 100% Stainless Steel Worm Gear Liner Hose Clamps SAE # 60 10pcs pack 3-5/16" - 4-1/4" (84mm-108mm) feature four piece heavy duty industrial grade quad-lock design allows more tightening torque compare to other aftermarket clamps. These HPS liner hose clamps features an inner protective sleeve which can prevent the damage of the silicone hose and delivers maximum protection and concentric seal to soft hoses. The HPS stainless steel worm gear liner hose clamps are ideal for aircraft, heavy-duty industrial applications as well as outdoor, fresh water and mildly corrosive applications. This HPS minature stainless steel clamp consist of stainless steel band, screw, saddle and housing. Technical Specification: SAE # 60. 100% Stainless Steel. 1/2 inch band. 5/16 inch (8mm) slotted hex screw. Four piece heavy duty industrial grade quad-lock design. Inner protective liner prevents the damage of the hose. Effective Diameter Range: 3-5/16" - 4-1/4" (84mm-108mm). Maximum Torque Spec: 35 in lbs. Exceeds all SAE requirements. REMARK: Sold in box of 10.

Key Features
Effective Diameter Range: 3-5/16" - 4-1/4" (84mm-108mm)
100% Stainless Steel
Sold in quantity of 5
Four piece heavy duty industrial grade quad-lock design, inner protective liner prevents the damage of the hose
Maximum Torque Spec: 35 in lbs, Exceeds all SAE requirements
1/2" band , 5/16" (8mm) slotted hex screw

HPS 100% Stainless Steel Worm Gear Liner Hose Clamps SAE # 60 5pcs pack 3-5/16" - 4-1/4" (84mm-108mm) feature four piece heavy duty industrial grade quad-lock design allows more tightening torque compare to other aftermarket clamps. These HPS liner hose clamps features an inner protective sleeve which can prevent the damage of the silicone hose and delivers maximum protection and concentric seal to soft hoses. The HPS stainless steel worm gear liner hose clamps are ideal for aircraft, heavy-duty industrial applications as well as outdoor, fresh water and mildly corrosive applications. This HPS minature stainless steel clamp consist of stainless steel band, screw, saddle and housing. Technical Specification: SAE # 60. 100% Stainless Steel. 1/2 inch band. 5/16 inch (8mm) slotted hex screw. Four piece heavy duty industrial grade quad-lock design. Inner protective liner prevents the damage of the hose. Effective Diameter Range: 3-5/16" - 4-1/4" (84mm-108mm). Maximum Torque Spec: 35 in lbs. Exceeds all SAE requirements. REMARK: Sold in box of 5.

Key Features
Effective Diameter Range: 4-5/8" - 5-1/2" (117mm-140mm)
100% Stainless Steel
Sold in Box of 10
Four piece heavy duty industrial grade quad-lock design, inner protective liner prevents the damage of the hose
Maximum Torque Spec: 35 in lbs, Exceeds all SAE requirements
1/2" band , 5/16" (8mm) slotted hex screw

HPS 100% Stainless Steel Worm Gear Liner Hose Clamps SAE # 80 10pcs pack 4-5/8" - 5-1/2" (117mm-140mm) feature four piece heavy duty industrial grade quad-lock design allows more tightening torque compare to other aftermarket clamps. These HPS liner hose clamps features an inner protective sleeve which can prevent the damage of the silicone hose and delivers maximum protection and concentric seal to soft hoses. The HPS stainless steel worm gear liner hose clamps are ideal for aircraft, heavy-duty industrial applications as well as outdoor, fresh water and mildly corrosive applications. This HPS minature stainless steel clamp consist of stainless steel band, screw, saddle and housing. Technical Specification: SAE # 80. 100% Stainless Steel. 1/2 inch band. 5/16 inch (8mm) slotted hex screw. Four piece heavy duty industrial grade quad-lock design. Inner protective liner prevents the damage of the hose. Effective Diameter Range: 4-5/8" - 5-1/2" (117mm-140mm). Maximum Torque Spec: 35 in lbs. Exceeds all SAE requirements. REMARK: Sold in box of 10.

Key Features
Effective Diameter Range: 4-5/8" - 5-1/2" (117mm-140mm)
100% Stainless Steel
Sold in quantity of 5
Four piece heavy duty industrial grade quad-lock design, inner protective liner prevents the damage of the hose
Maximum Torque Spec: 35 in lbs, Exceeds all SAE requirements
1/2" band , 5/16" (8mm) slotted hex screw

HPS 100% Stainless Steel Worm Gear Liner Hose Clamps SAE # 80 5pcs pack 4-5/8" - 5-1/2" (117mm-140mm) feature four piece heavy duty industrial grade quad-lock design allows more tightening torque compare to other aftermarket clamps. These HPS liner hose clamps features an inner protective sleeve which can prevent the damage of the silicone hose and delivers maximum protection and concentric seal to soft hoses. The HPS stainless steel worm gear liner hose clamps are ideal for aircraft, heavy-duty industrial applications as well as outdoor, fresh water and mildly corrosive applications. This HPS minature stainless steel clamp consist of stainless steel band, screw, saddle and housing. Technical Specification: SAE # 80. 100% Stainless Steel. 1/2 inch band. 5/16 inch (8mm) slotted hex screw. Four piece heavy duty industrial grade quad-lock design. Inner protective liner prevents the damage of the hose. Effective Diameter Range: 4-5/8" - 5-1/2" (117mm-140mm). Maximum Torque Spec: 35 in lbs. Exceeds all SAE requirements. REMARK: Sold in box of 5.

Key Features
Four piece heavy duty industrial grade quad-lock design, inner protective liner prevents the damage of the hose
Maximum Torque Spec: 35 in lbs, Exceeds all SAE requirements
1/2" band , 5/16" (8mm) slotted hex screw
Effective Diameter Range: 5-5/8" - 6-1/2" (130mm-152mm)
100% Stainless Steel
Sold in Box of 10

HPS 100% Stainless Steel Worm Gear Liner Hose Clamps SAE # 88 10pcs pack 5-5/8" - 6-1/2" (130mm-152mm) feature four piece heavy duty industrial grade quad-lock design allows more tightening torque compare to other aftermarket clamps. These HPS liner hose clamps features an inner protective sleeve which can prevent the damage of the silicone hose and delivers maximum protection and concentric seal to soft hoses. The HPS stainless steel worm gear liner hose clamps are ideal for aircraft, heavy-duty industrial applications as well as outdoor, fresh water and mildly corrosive applications. This HPS minature stainless steel clamp consist of stainless steel band, screw, saddle and housing. Technical Specification: SAE # 88. 100% Stainless Steel. 1/2 inch band. 5/16 inch (8mm) slotted hex screw. Four piece heavy duty industrial grade quad-lock design. Inner protective liner prevents the damage of the hose. Effective Diameter Range: 5-5/8" - 6-1/2" (130mm-152mm). Maximum Torque Spec: 35 in lbs. Exceeds all SAE requirements. REMARK: Sold in box of 10.

Key Features
Effective Diameter Range: 5-5/8" - 6-1/2" (130mm-152mm)
100% Stainless Steel
Sold in quantity of 5
Four piece heavy duty industrial grade quad-lock design, inner protective liner prevents the damage of the hose
Maximum Torque Spec: 35 in lbs, Exceeds all SAE requirements
1/2" band , 5/16" (8mm) slotted hex screw

HPS 100% Stainless Steel Worm Gear Liner Hose Clamps SAE # 88 5pcs pack 5-5/8" - 6-1/2" (130mm-152mm) feature four piece heavy duty industrial grade quad-lock design allows more tightening torque compare to other aftermarket clamps. These HPS liner hose clamps features an inner protective sleeve which can prevent the damage of the silicone hose and delivers maximum protection and concentric seal to soft hoses. The HPS stainless steel worm gear liner hose clamps are ideal for aircraft, heavy-duty industrial applications as well as outdoor, fresh water and mildly corrosive applications. This HPS minature stainless steel clamp consist of stainless steel band, screw, saddle and housing. Technical Specification: SAE # 88. 100% Stainless Steel. 1/2 inch band. 5/16 inch (8mm) slotted hex screw. Four piece heavy duty industrial grade quad-lock design. Inner protective liner prevents the damage of the hose. Effective Diameter Range: 5-5/8" - 6-1/2" (130mm-152mm). Maximum Torque Spec: 35 in lbs. Exceeds all SAE requirements. REMARK: Sold in box of 5.
