GReddy OIL COOLER KIT W/ FILTER RELOCATION JZA80 16-ROW - () 12014405

Oil cooler kit moving 16row for JZA80

Product Features

• An ideal oil cooler that uses a large-capacity core with offset fins in the core tube to increase heat dissipation and reduce pressure loss.
• A type of kit that can be installed on cars that do not have clearance near the oil filter.
• By moving the element, it is easier to replace the oil filter and improve maintenance.

Product Specifications

• Core type: NS1610G
• Thermostat: Built-in block
• Core installation position: In front of radiator
• Element installation location: Next to the air conditioner compressor
• Center bolt size: 3/4-16UNF

Compatible models: TOYOTA Supra

• Vehicle model: JZA80
• E/G model: 2JZ-GTE
• Year: 93.05-02.08
• CODE:12014405

Remarks

• Cannot be installed on AT vehicles
• rear car unconfirmed
• Under cover, fender splash shield processing required
