Garrett GTX3582R Gen II Turbo Assembly Kit T3 / V-Band 1.06 A/R
Garrett GTX3582R Gen II Turbo Assembly Kit T3 / V-Band 1.06 A/R
sku: 1DRUE | mpn: 856801-5067S
Regular price
$3,167.79
Regular price
$3,167.79
Sale price
$3,167.79
Shipping calculated at checkout.
Out of stock
Emissions
This is not an emissions item.
Quantity
Couldn't load pickup availability
- Ships Worldwide
- Easy Returns
- Fast Shipping
Horsepower: 450 - 850
Displacement: 2.0L - 4.5L
Features:
- Gen 2 Aerodynamics Feature Increased Horsepower Range
- New Fully-machined Speed Sensor Port.
- Sold As Assembly Kits (Super Core + Turbine Kit)
- New Reverse Rotation Options Available
Specification
| Compressor | Turbine | |||||||
|---|---|---|---|---|---|---|---|---|
| Super Core Reference Data | Inducer | Exducer | Trim | A/R | Inducer | Exducer | Trim | |
| GTX3582R Standard Rotation | 66mm | 82mm | 64 | 0.70 | 68mm | 62mm | 84 | |
| GTX3582R Reverse Rotation | 66mm | 82mm | 64 | 0.70 | 68mm | 62mm | 84 | |
| Notes: | Assembly Kit PN | Super Core PN | Turbine Kit PN | A/R | Inlet | Outlet | Wastegate | Divided |
| Assembly Kit PN Includes Super Core and Turbine Kit | ||||||||
| 856801-5067S | 851154-5004S | 740902-0010 | 1.06 | T3 | V-Band | Free Float | N | |
