Garrett Gen II Turbo Assembly Kit V-Band

Garrett GTX3076R - Gen. II - 856801-5039S

V-band inlet - V-band outlet - Ext. Wastegate -.  0.61 A/R -.

The new Garrett GTX gene. II turbochargers are latest development by Garrett in the racing segment.

Power: 400-750 PS

Capacity:  1.8 -3.0 l

Direction of rotation: Standard

Impeller:

Inlet: 58,00 mm

Outlet: 76,00 mm

A / R: 0.60

Turbine wheel:

Einalss: 60.00 mm

Outlet: 55,00 mm

A/R: 0.61
