Garrett GT2860RS Dual Ball Bearing Turbocharger

• Original GT series aerodynamics
• Internally wastegated turbine housing
• GT2860RS Dual Ball Bearing Turbocharger
• Ball bearing configuration with water cooled CHRA
• V-Band turbine housing options
• Horsepower: 250 - 360
• Displacement: 1.8L - 3.0L

Specifications

• Compressor
  • Inducer: 47mm
  • Exducer: 60mm
  • Trim: 62
  • A/R: 0.60
•  Turbine
  • Inducer: 54mm
  • Exducer: 47mm
  • Trim: 76
  • A/R: 0.64
