Carter Fuel Pump-Electric in Line

The Carter Fuel Systems program features unique innovation and solutions by offering premium fit, form, and function for exceptional vehicle coverage and exclusive problem-solving features. Carter Fuel replacement Electric Pumps consistently deliver fuel at the precise pressure and flow rate the vehicle demands.

Specifications

National Popularity Code: (C) Next 15% of Product Group Sales Value

Pallet Layer Maximum: 5

Maximum Cases per Pallet Layer: 15

Fuel Pump Inlet Type: Hose Barb

Fuel Sending Unit Included: No

Negative Ground: Yes

Inlet Outside Diameter: 9.4 mm

Outlet Outside Diameter: 9.4 mm

Voltage: 12 VDC

Length: 139.0 mm

Internal Or External: External

Regulator Included: No

Maximum Pressure: 5.0 PSI

Terminal Type: Pin

Mounting Hardware Included: Yes

Universal Or Specific Fit: Universal

Wire Quantity: 2

Connector Shape: N/A

Gasket Or Seal Included: No

Terminal Quantity: 2

Seal And Lock Ring Included: No

Terminal Gender: Male

Wiring Harness Included: No

Strainer Included: No

Inlet Type: Hose Barb

Outlet Type: Hose Barb

Outlet Quantity: 1

Minimum Pressure: 2.0 PSI

Pump Design: Rotary Vane

Minimum Flow Rating: 50 gph

Mounting Bracket Included: Yes

Pump Type: Electric
