Dorman Frame Repair Kit

Chassis Frame Repair Kit

This Frame Repair Kit includes everything required to repair this section of rusted or damaged chassis frame. Made of heavy-gauge steel and finished in weldable primer, this frame repair kit includes all original equipment hardware mounting positions.

• Saves money - replace only damaged frame section, not the entire frame
• Improved design - re-engineered with improved drainage to prevent future corrosion buildup
• Restores vehicle performance - ensures proper suspension alignment for predictable handling
• Vehicle tested - has undergone on-vehicle testing to ensure proper fit and performance

Product Specifications

Bolt Grade: 10.9
Bracket Depth: 73 mm
Bracket Included: Yes
Bracket Length: 490 mm
Bracket Shape: Rectangular
Bracket Width: 173 mm
Color: Weldable Primer
Configuration: One Piece
Cutting Required: Yes
Drilling Required: No
Material: Steel
Material Thickness: 4.6 mm
Package Contents: 1 Frame Bracket; 2 Bolts; 2 Nuts
Rivets Included: No
Screws Included: Yes
Universal Or Specific Fit: Specific

Application Summary: Jeep Wrangler 2003-97

Vehicle Fitments:
