FelPro Intake Manifold Gasket Set

Fel-Pro® Performance Gaskets deliver reliable sealing under grueling racing conditions

• Fel-Pro performance intake manifold gaskets have been tested with virtually all aftermarket cylinder head and intake manifold combinations.
• Designed for high-vacuum applications, this solid metal core intake gasket prevents movement of the gasket into the intake port, which can lead to engine power loss.
• Ideal for circle track racing running restrictor plates, drag cars running throttle stops, and long service life engines such as those in street applications.
• Top gasket; Second design, Box manifold.
• Not intended for use in emission controlled vehicles.

Specifications

Part Type: Intake Manifold Gasket Set

Mfg.: GM Performance

Engine Family: Chevrolet V6

Engine Displacement: (4.3L) 262 Turbo, 229 (3.8L), 262 (4.3L)

Port Size (in.): Not applicable

Port Shape: Open Plenum

Thickness (in.): 0.047

Materials/Construction: Steel core laminate w/silicone coating

Application Notes: Top gasket - Second design, Box manifold
