Fabtech 05-20 Ford F250/350 / 08-20 Ford F450/550 4WD 4/6/8in Lift Radius Arm System FTS22321

Fabtech 05-20 Ford F250/350 / 08-20 Ford F450/550 4WD 4/6/8in Lift Radius Arm System FTS22321

Regular price $787.63
Regular price Sale price $787.63
Sale Sold out

Shipping calculated at checkout.

Low stock: 3 left

Quantity

Shipping & returns

Shipping details

In-stock orders are processed within 48 hours; transit time is additional.

International orders include export processing and customs clearance. Duties, taxes and brokerage are extra; final freight charges may change after remeasurement.

Read the shipping policy

Returns

Need help with a return? Request authorization within 30 days of delivery for eligible unused, uninstalled items. See details for exclusions and applicable fees.

Read the full return policy
Return details & how to start

Request return authorization (RMA) within 30 days of delivery for eligible items. Keep items unused and uninstalled, with original packaging and accessories. Electronics, liquids, special orders and other categories are excluded.

Email sales@frsport.com with RETURN and your order number in the subject to request an RMA. Please wait for return authorization before sending your item back.

Wrong part/size or change of mind: a 20% return processing fee applies, plus applicable shipping costs.

Original shipping is non-refundable. For orders shipped free, the actual outbound shipping cost is deducted from the refund. Return shipping is prepaid by the customer.

After payment capture, cancellations and refunds generally incur a 5% processing fee, except for our error, confirmed defects or confirmed carrier loss. The 5% and 20% fees do not stack; only the greater applicable fee applies. Store credit waives the 5% fee, but applicable return fees remain.

Missing, incorrect or transit-damaged items: report within 3 business days of receipt with photos of the product and packaging.

For defective items, contact us for help with the manufacturer's warranty process. The manufacturer decides the claim.

Specifications

Product details shared across all variants.

Product type
Suspension Lift Kit
Category
Motor Vehicle Suspension Parts
Item condition
New
Manufacturer type
Aftermarket
Shipping weight
63.0 lb
Barcode
674866110724

Billable shipping weight; may include dimensional weight.

Fabtech Lift Kits FTS22321 2005-20 Ford F250/F350 4WD. 2008-19 Ford F450/F550 4WD. Fabtech's legendary Radius Arms are the perfect upgrade to the Ford Super Duty front suspension for lifted applications. The heavy duty tubular construction adds strength with a race component style to the vehicle for aggressive offroad use. These Super Duty Radius Arms directly replace the factory arms for use with lifted 4" to 8" suspensions. The arms have an additional 1 degree of caster built into the arms and with the easy adjustment alignment cams gives a total of 2 degrees more caster than stock. A big benefit for taller 6" and 8" lifted vehicles to improve highway tracking. The upper and lower tubes of the arms are constructed with 1.75" OD x .120" wall DOM tubing and are fully welded closed to prevent corrosion. Spanning between the tubes is a dimple die side plate that adds rigidity to the arm for strength with minimal weight gain. Radius Arms are offset and positioned inboard compared to the stock arms to allow full steering lock with a 13.50 wide tire on a 5" backspace wheel. The Fabtech Super Duty Radius Arms are an open design so that powdercoat can cover the entire arm. This design is superior in coating coverage compared to boxed arms that are stitch welded and have gaps that allow moisture to get and cause rust. Fabtech's Radius Arms have been proven for over 15 years in consumer, commercial and military applications. There are no better Radius Arms for your Super Duty. Features: Constructed with 1.75" OD x .120" wall DOM tubing. Directly replace factory arms on lifted vehicles. Additional caster to improve tracking. 4"/6"/8" RADIUS ARM BOX Radius Arm Lift System; 1.75 OD x .120 in. Wall DOM Tubing; Fits 4 in./6 in. And 8 in. Suspension System; 4"/6"/8" RADIUS ARM

Vehicle Fitments:

Year Make Model Submodel
2015 - 2016 Ford F-250 Super Duty Base
2009 - 2010 Ford F-250 Super Duty Cabela's
2008 - 2014 Ford F-250 Super Duty FX4
2005 - 2010 Ford F-250 Super Duty Harley-Davidson Edition
2005 - 2020 Ford F-250 Super Duty Lariat, XL, King Ranch, XLT
2018 - 2020 Ford F-250 Super Duty Limited
2013 - 2020 Ford F-250 Super Duty Platinum
2009 - 2010 Ford F-350 Super Duty Cabela's
2008 - 2009 Ford F-350 Super Duty FX4
2005 - 2010 Ford F-350 Super Duty Harley-Davidson Edition
2018 - 2020 Ford F-350 Super Duty Limited
2013 - 2020 Ford F-350 Super Duty Platinum
2017 - 2020 Ford F-350 Super Duty XL Plus
2005 - 2020 Ford F-350 Super Duty XLT, Lariat, King Ranch, XL
