Edelbrock Cylinder Head E-Cnc GM Gen IIi/IV LS3 Small Port Lsx Block 61329
Edelbrock Cylinder Head E-Cnc GM Gen IIi/IV LS3 Small Port Lsx Block 61329
sku: 10QYE | mpn: 61329
Regular price
$2,302.49
Regular price
Sale price
$2,302.49
Out of stock
Not sure this is the right part? Ask us to check fitment. Include your year, make, model, engine and manufacturer part number.
Quantity
Need this part?
This item is currently unavailable. Ask us about availability or help finding a suitable replacement.
Shipping & returns
This selection is unavailable. Ask us to confirm availability and timing.
Shipping details
In-stock orders are processed within 48 hours; transit time is additional.
International orders include export processing and customs clearance. Duties, taxes and brokerage are extra; final freight charges may change after remeasurement.
Read the shipping policy
Edelbrock Heads 61329 Cylinder Head Specifications: Combustion chamber volume: 69cc; Intake runner volume: 230cc; Exhaust runner volume: 80cc; Intake valve diameter: 2.135"; Exhaust valve diameter: 1.55"; Valve stem diameter: 8mm; Valve guides: Manganese bronze; Deck thickness: 5/8"; Valve spring diameter: 1.30"; Valve spring maximum lift: .680"; Rocker stud: N/A; Guideplate: N/A; Pushrod diameter: 5/16"; Valve angle: 13.25░; Exhaust port location: 0.125" Raised Port; Spark plug fitment: 14mm x 3/4 reach, gasket seat. * Our E-CNC LS3 Cylinder Heads are a great general-purpose high performance cylinder head for any street- strip LS engine. These cylinder heads have a high velocity port compared to stock LS3 cylinder heads, making them an ideal upgrade for any cathedral port or 3.89" bore LS application. They feature an improved design and casting that gives cylinder head porters more material to work with compared to stock heads. Like all of our other E-CNC cylinder heads, these feature fully CNC'd intake ports, combustion chambers and exhaust ports for improved performance. Compatible with stock style rocker arms. * Match with Edelbrock head gasket sets. Recommended spark plugs are Champion RC12YC or equivalent 14mm x 3/4" reach with flat gasket seat. IMPORTANT NOTES; E-CNC LS3 cylinder heads are a great general purpose high performance cylinder head for any street- strip LS engine. These cylinder heads have a high velocity port compared to stock LS3 cylinder heads, making them an ideal upgrade for any cathedral port or 3.89" bore LS application. They feature an improved design and casting that gives cylinder head porters more material to work with compared to stock heads. Compatible with stock style rocker arms. Features an exhaust port that has been raised 0.125" as well as raised spring pockets that have been machined 0.200" for use with longer valves. CYLINDER HEAD Cylinder Head; E-CNC; GM; Gen III/IV LS3; Small Port; LSX Block CYLINDER HEADS
