Earl's -12 Ultra Pro Hinge Type Check Valve

Earl's -12 Ultra Pro Hinge Type Check Valve

sku: 00U01 | mpn: 253012ERL
$136.95
$136.95 $136.95
Sale Sold out
Shipping calculated at checkout.

Out of stock

Emissions

This is not an emissions item.
  • Ships Worldwide
  • Easy Returns
  • Fast Shipping
Earl's is pleased to release a new one-way check valve that is ideal for use on fuel and oil systems. Now offered with internal stainless steel hinge and GF-600S Viton® seal. The GF-600S Viton® is the highest quality seal material for all types of fuels including diesel & alcohol. The Internal spring releases to full flow at 1 psi (Note: blowing through it will only partially release the hinge). High PSI Rating is 1250 PSI. This product uses a proven military design & provides for a more compact unit over conventional flapper check valves.

FEATURES:

  • High Quality Check Valve w/ Stainless Steel Hinge Door - Proven Military Style Design
  • Seal Material: GF-600S Viton® - Peroxide-Curable Polymer Designed to Provide Outstanding Performance
  • Ideal for Use w/ Fuels, Oil, Coolant, Air, Diesel, Methanol & Ethanol
  • Valve Opens Fully at 1 PSI (Note: blowing through it will only partially release the hinge)
  • Maximum Pressure 1250 PSI
  • Body is Anodized Aluminum


SPECIFICATION

Adapter Type: Check Valve
Body Length: 1.85"
Diameter: 1.50"
Emission Code: 1
Finish: Anodized Pewter
Inlet / Outlet Size: 12 AN MALE
Material: Aluminum
Overall Dimension: 3.50"
Product Type: Check Valve
PSI Rating: 1250
Seal Material: GF-600S Viton®
