Earl's Ultra Pro Hinge Type Check Valve -8
Earl's Ultra Pro Hinge Type Check Valve -8
Out of stock
Not sure this is the right part? Ask us to check fitment. Include your year, make, model, engine and manufacturer part number.
Need this part?
This item is currently unavailable. Ask us about availability or help finding a suitable replacement.
Shipping & returns
This selection is unavailable. Ask us to confirm availability and timing.
Shipping details
In-stock orders are processed within 48 hours; transit time is additional.
International orders include export processing and customs clearance. Duties, taxes and brokerage are extra; final freight charges may change after remeasurement.
Read the shipping policyEarl's is pleased to release a new one-way check valve that is ideal for use on fuel and oil systems. Now offered with internal stainless steel hinge and GF-600S Viton® seal. The GF-600S Viton® is the highest quality seal material for all types of fuels including diesel & alcohol. The Internal spring releases to full flow at 1 psi (Note: blowing through it will only partially release the hinge). High PSI Rating is 1250 PSI. This product uses a proven military design & provides for a more compact unit over conventional flapper check valves.
Features:
- High Quality Check Valve w/ Stainless Steel Hinge Door – Proven Military Style Design
- Seal Material: GF-600S Viton® - Peroxide-Curable Polymer Designed to Provide Outstanding Performance
- Ideal for Use w/ Fuels, Oil, Coolant, Air, Diesel, Methanol & Ethanol
- Valve Opens Fully at 1 PSI (Note: blowing through it will only partially release the hinge)
- Maximum Pressure 1250 PSI
- Body is Anodized Aluminum
SPECS
Adapter Type: Check Valve
Body Length: 1.35"
Brand: Earls
Diameter: .930 in
Emission Code: 1
Finish: Anodized Pewter
Inlet / Outlet Size: 8 AN MALE
Material: Aluminum
Overall Dimension: 2.75"
Product Type: Check Valve
PSI Rating: 1250
Seal Material: GF-600S Viton®
