CSF OEM Plastic Radiator 3717 *Discontinued

CSF OEM Plastic Radiator

Radiator

CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years - over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road

Features and Benefits:

100% leak tested before leaving factory at 150% of operating pressure
All components are installed, torqued, & tested on Radiator during assembly
Drop-in Fit
Fins (Heart of Radiator) - High Performance "Multi-Louvered Design" - OEM Spec
Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120 Degrees F
High Performance Transmission Cooler with special Built-in Turburlator, when applicable
Industry Best Packaging - "10 Foot Drop Test" Standard
OEM specified Plastic Tank-Aluminum Core Construction
Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
Tubes - Welded Type or Latest Generation "B-Tube" Design

Specifications:

Bottom Hose Fitting (in) 1 1/2 Right
Box Height (in) 5 7/8
Box Length (in) 29 7/16
Box Weight (lbs) 8
Box Width (in) 17 1/16
Core Length (in) 23 5/8
Core Material Aluminum
Core Thickness (in) 1 1/4
Core Width (in) 13 5/8
Cross-flow/ Down-flow Cross Flow
Hazardous Material No
Inlet Length (in) 14 1/8
Inlet Width (in) 1 13/16
No. Of Rows 1
Outlet Length (in) 14 1/8
Outlet Width (in) 1 13/16
Radiator Cap Supplied No
Tank Material Plastic
Tech Note O.E.M. style Plastic tanks & Aluminum core;with quick-connect inlet & outlet pipe;Supplied with Cooling Circuit "Control Sleeve".
Top Hose Fitting (in) 1 1/2 Left

Vehicle Fitments:
