Crower Ford 2.3L DOHC Duratec Stage 3 Camshafts - Pair

Ford 2.0 & 2.3L DOHC Duratec Stage 3 Camshaft

Engine Make: Ford / Mazda

Year: 2003-2007

Part Class: Camshaft

Camshaft Name: Stage 3 - Full Race

Camshaft Series: Original

Engine Type: 4 Cylinder

Engine Size: 2.0L & 2.3L Duratec

Valve Lash:  .006" intake and .008" exhaust

Lobe center: 112

Advertised Duration: Intake / Exhaust:  284 / 276

Duration @ .050" Lift: Intake / Exhaust:  236 / 228

Lobe Lift: Intake / Exhaust: .414 / .393

Rocker Ratio: Intake / Exhaust: 1 / 1

Gross Valve Lift: Intake / Exhaust:  .414 / .393

Performance Level: 5

Low RPM: 1100

Peak HP: 8000

Redline: 8500

Performance Description: Drag Race and radical Street/Strip. Requires #84170 spring kit and compatible ECU upgrade for optimum results. Rough idle.

Engine Application:  Level 5 camshafts are designed for fully prepared, high compression all-out racing engines and chassis.

Recommended Modifications: Extensive cylinder head modification, bigger titanium valves, lightweight valve train, maximum flow carburetion or fuel injection, racing gas (alcohol or nitro), magneto or electronic ignition, performance rod and crank assembly and increased engine clearances are required for maximum benefit.

Recommended Kit #1:  84170
