• Aeroquip Fuel Fittings and Adapters FBM4084 Item Image
1 1
Aeroquip Authorized Dealer

Aeroquip -10AN Hose Size; 60 Deg. Elbow; Reusable Aluminum Swivel

Aeroquip -10AN Hose Size; 60 Deg. Elbow; Reusable Aluminum Swivel

sku: 10ZE9 | mpn: FBM4084
$30.46
$63.99 $30.46
Sale Sold out
Shipping calculated at checkout.

Out of stock

Emissions

This is not an emissions item.
  • Ships Worldwide
  • Easy Returns
  • Fast Shipping

GENERAL SPECIFICATIONS

PRODUCT LENGTH: 3.53 IN
PRODUCT HEIGHT: .932 IN
PRODUCT WIDTH: 1.0625 IN
PRODUCT WEIGHT: .01 LB

PRODUCT SPECIFICATIONS

COMPATIBLE HOSES: FBA
ITEM TYPE: Fitting Assembly
PRODUCT MATERIAL: Aluminum
THREAD SEALANT: No
HOSE DASH SIZE: -10
OUTSIDE DIAMETER: 1.0625 IN
FINISH/PLATING: Red / Blue Anodized
ANGLE (SHAPE): 60 Degree
INSIDE DIAMETER: .47 IN
HEX SIZE 1: 1 IN
DROP DIMENSION: .932
THREAD SIZE 1: 7/8-14
CONSTRUCTION STYLE: Reusable
END TYPE 2: Line/Hose/Tube
END GENDER 1: Female
END TYPE 1: SAE 37
HOSE CUT-OFF FACTOR: 2.65 IN
HEX SIZE 2: 1.0625 IN
View full details
