Garrett Turbocharger GTX 2860R

Garrett Turbocharger GTX 2860R

sku: 1DRV7 | mpn: 856800-5004S
$1,799.11
$2,141.80 $1,799.11
Sale Sold out
Shipping calculated at checkout.

Low stock: 2 left

Emissions

⚠️ RACING/COMPETITION Use Only

California: Non-compliant parts may be used only on designated closed-course racing vehicles that are never registered for highway use.

Other: Please consult your local statutes and ordinances to ensure compliance with regional emissions standards.

  • Ships Worldwide
  • Easy Returns
  • Fast Shipping

856800-5004S Garrett GTX2860R GEN II Ball Bearing Turbocharger

Inlet: T25

Outlet: 5 bolt

A/R: 0.86

Wastegated: Yes

Divided: N

  • Gen 2 Aerodynamics feature increased horspower range
  • Improved Ported Shroud design for surge resistance
  • New fully machined speed sensor port
  • Horespower: 200 - 475
  • Displacement: 1.4L - 2.5L

WARNING - On some applications a secondary 0.040" oil feed restrictor may be required. If the oil pressure exceeds 40 to 45 psi at maximum engine speed then it is recommend to fit the secondary restrictor to prevent oil being forced past the pressure differential oil seals and the turbo being incorrectly diagnosed as faulty.
