| PART No. | PRODUCT NAME | |
|---|---|---|
| TB6090-SB06A | FULL TITANIUM MUFFLER KIT EXPREME Ti WRX 2022+ TYPE-R INVENTORY→ |
 |
| TB6090-SB06B | FULL TITANIUM MUFFLER KIT EXPREME Ti WRX 2022+ TYPE-D INVENTORY→ |
 |
APPLICATION
| MAKER | ENGINE | MODEL |
|---|---|---|
| SUBARU | FA24DIT | WRX 2022+ |
FULL TITANIUM MUFFLER SPECIFICATION
| TOMEI | OEM | ||
|---|---|---|---|
| TYPE-R | TYPE-D | ||
| PART No. | TB6090-SB06A | TB6090-SB06B | - |
| MATERIAL | TITANIUM | - | |
| MAIN PIPE DIAMETER | 3.2inch [80.5mm] |
3.2inch [80.5mm ] |
2.4 inch [60.0mm] |
| MAIN PIPE THICKNESS | 1.0mm | - | |
| SUB SILENCER DIAMETER | 4.7inch [118.0mm] |
4.7inch x 2 [118.0mm x 2] |
19.0*8.7*4.3inch [480*220*110 mm] |
| SUB SILENCER THICKNESS | 1.0mm | - | |
| SILENCER DIAMETER | 6.0inch [152.0mm] |
6.0inch x 2 [152.0mm x 2] |
(14.0*12.0*90inch) x 2 [(350*300*230 mm) x 2] |
| SILENCER THICKNESS | 1.0mm | - | |
| EXIT DIAMETER | 4.5inch [115.0mm)] |
4.5inch x 2 [115.0mm x 2] |
3.1inch x 4 [80.0mm] x 4 |
| EXIT THICKNESS | 1.0mm | - | |
| FLANGE THICKNESS | 8.0mm | - | |
| WEIGHT | 17.9lbs [8.1kg] |
26.5lbs [12.0kg] |
48.1lbs [21.8kg] |
Only muffler installed.
| TYPE-R | TYPE-D | |
|---|---|---|
 withSound Reducer ver.2 |
89db | 85db |
 withSound Reducer |
95db | 90db |
| without Sound Reducer |
99db | 95db |
This kit includes all the components necessary for installation including the bolts and nuts. Bolt Smooth Paste is also included to help prevent the bolts becoming seized under heat.
EXHAUST PRODUCTS COMPATIBILITY LIST
| MAKE | MODEL | CATEGORY | MATERIAL | TYPE | PARTS NO. |
|---|---|---|---|---|---|
| NISSAN INFINITI |
35 GT-R | MUFFLER | TI | QUAD | TB6070-NS01A |
| 400Z | MUFFLER | TI | SINGLE | TB6090-NS21C | |
| DUAL | TB6090-NS21D | ||||
| 370Z | MUFFLER | TI | SINGLE | TB6090-NS02A | |
| Y PIPE | TI | TB6110-NS02A | |||
| MID PIPE | TI | TB6100-NS02A | |||
| 350Z | MUFFLER | TI | SINGLE | TB6090-NS04A | |
| EX-MANIFOLD | SUS | VQ35DE | TB6010-NS04A | ||
| Y PIPE | TI | TB6110-NS02A | |||
| MID PIPE | TI | VQ35DE | TB6100-NS04A | ||
| VQ35HR | TB6100-NS02A | ||||
| 32 GT-R | MUFFLER | TI | SINGLE | TB6090-NS05A | |
| 33 GT-R | MUFFLER | TI | SINGLE | TB6090-NS05B | |
| 34 GT-R | MUFFLER | TI | SINGLE | TB6090-NS05C | |
| 32,33,34 GT-R | EX-MANIFOLD | SUS | TB6010-NS05A | ||
| TURBINE OUTLET | SUS | TB6020-NS05A | |||
| FRONT PIPE | TI | TB6080-NS05A | |||
| 34 SKYLINE 2DOOR |
MUFFLER | TI | SINGLE | TB6090-NS06A | |
| 34 SKYLINE 4DOOR |
MUFFLER | TI | SINGLE | TB6090-NS06B | |
| 32,33,34 SKYLINE |
TURBINE OUTLET | SUS | RB20,25DET | TB6020-NS06A | |
| 13 SILVIA, 180SX,240SX |
MUFFLER | TI | SINGLE | TB6090-NS08A | |
| 14 SILVIA, 240SX |
MUFFLER | TI | SINGLE | TB6090-NS08B | |
| 15 SILVIA | MUFFLER | TI | SINGLE | TB6090-NS08C | |
| 13,14,15 SILVIA,180SX | EX-MANIFOLD | SUS | SR20DET | TB6010-NS08A | |
| TURBINE OUTLET | SUS | SR20DET | TB6020-NS08C | ||
| VARIOUS NISSAN |
MID PIPE | TI | TYPE-A | TB6100-NS00A | |
| Q60 | MUFFLER | TI | SINGLE | TB6090-NS21B | |
| Y PIPE | TI | TB6110-NS21A | |||
| G35 COUPE SKYLINE V35 COUPE | MUFFLER | TI | SINGLE | TB6090-NS04G | |
| G35 | EX-MANIFOLD | SUS | VQ35DE | TB6010-NS04A | |
| Y PIPE | TI | TB6110-NS02A | |||
| MID PIPE | TI | VQ35DE | TB6100-NS04A | ||
| Q50,RV37 SKYLINE | MUFFLER | TI | SINGLE | TB6090-NS21A | |
| Q50,SKYLINE 400R | Y PIPE | TI | TB6110-NS21A | ||
| SUBARU | WRX,WRX STI GDF USDM | MUFFLER | TI | SINGLE | TB6090-SB02A |
| WRX, WRX STI GD |
DOWN PIPE | SUS | EJ25 | TB6060-SB02A | |
| WRX,WRX STI GRF USDM | MUFFLER | TI | SINGLE | TB6090-SB02B | |
| WRX,WRX STI GVF/VA USDM | MUFFLER | TI | SINGLE | TB6090-SB02C | |
| WRX,WRX STI GR/GV/GE/ GH/VA |
DOWN PIPE | SUS | EJ25 | TB6060-SB02B | |
| 2002+ WRX 2004+ WRX STI | EX-MANIFOLD | SUS | UNEQUAL | TB6010-SB02A | |
| EQUAL | TB6010-SB02B | ||||
| 2015+ WRX | EX-MANIFOLD | SUS | UNEQUAL | TB6010-SB04A | |
| EQUAL | TB6010-SB04B | ||||
| MID PIPE | TI | TB6100-SB04A | |||
| 2022+ WRX | MUFFLER | TI | SINGLE | TB6090-SB06A | |
| DUAL | TB6090-SB06B | ||||
| WRX,WRX STI GDB A-D JDM | MUFFLER | TI | SINGLE | TB6090-SB01A | |
| WRX,WRX STI GDB E-G JDM | MUFFLER | TI | SINGLE | TB6090-SB01B | |
| WRX, WRX STI GR JDM |
MUFFLER | TI | SINGLE | TB6090-SB01C | |
| WRX, WRX STI GV JDM |
MUFFLER | TI | SINGLE | TB6090-SB01D | |
| WRX STI TWIN SCROOL | EX-MANIFOLD | SUS | EQUAL | TB6010-SB01A | |
| SUBARU, TOYOTA |
2013+ 86,BRZ, SCION FR-S |
MUFFLER | TI | SINGLE 60S | TB6090-SB03A |
| SINGLE 60R | TB6090-SB03B | ||||
| SINGLE 80 | TB6090-SB03C | ||||
| SINGLE 80 ver.2 | TB6090-SB05A | ||||
| DUAL | TB6090-SB05B | ||||
| EX-MANIFOLD | SUS | UNEQUAL | TB6010-SB03B | ||
| EQUAL | TB6010-SB03A | ||||
| JOINT PIPE | SUS | TB6060-SB03A | |||
| MID PIPE | TI | FOR 60S,60R (M/T ONLY) |
TB6100-SB03A | ||
| FOR 80,ver2,DUAL (M/T ONLY) |
TB6100-SB03B | ||||
| BUMPER COVER | CARBON | EARLY LH | TE301A-SB03A | ||
| EARLY RH | TE301A-SB03B | ||||
| FRP | 86 LATE LH | TE301A-SB03C | |||
| 86 LATE RH | TE301A-SB03D | ||||
| 2021+ GR86, BRZ |
MUFFLER | TI | SINGLE 80 ver.2 | TB6090-SB05A | |
| DUAL | TB6090-SB05B | ||||
| MID PIPE | TI | FOR 80,ver2,DUAL (M/T ONLY) |
TB6100-SB03B | ||
| TOYOTA | GR SUPRA | MUFFLER | TI | SINGLE | TB6090-TY06A |
| TI | DUAL | TB6090-TY06B | |||
| 80 SUPRA | MUFFLER | TI | SINGLE | TB6090-TY03A | |
| MID PIPE | TI | TB6110-TY03A | |||
| ADAPTER | TI | TB6120-0000A | |||
| 86 LEVIN/TRUENO | MUFFLER | TI | SINGLE R | TB6090-TY01A | |
| SINGLE S | TB6090-TY01B | ||||
| MID PIPE | TI | TB6100-TY01A | |||
| 100 CHASER,MARK2 | MUFFLER | TI | SINGLE | TB6090-TY04A | |
| TURBINE OUTLET | SUS | TB6020-TY04A | |||
| HONDA | FL5 CIVIC TYPE-R |
MUFFLER | TI | SINGLE | TB6090-HN06D |
| DUAL | TB6090-HN06E | ||||
| FK5 CIVIC TYPE-R |
MUFFLER | TI | SINGLE R | TB6090-HN06A | |
| SINGLE S | TB6090-HN06B | ||||
| S2000 | MUFFLER | TI | SINGLE | TB6090-HN04A | |
| MID PIPE | TI | TB6100-HN04A | |||
| DUAL | TB6090-HN06C | ||||
| MAZDA | NA MX-5 | MUFFLER | TI | SINGLE | TB6090-MZ01A |
| NB MX-5 | MUFFLER | TI | SINGLE | TB6090-MZ02A | |
| NC MX-5 | MUFFLER | TI | SINGLE | TB6090-MZ03A | |
| MID PIPE | TI | TB6100-MZ03A | |||
| ND MX-5 | MUFFLER | TI | SINGLE | TB6090-MZ06A | |
| FD RX-7 | MUFFLER | TI | SINGLE | TB6090-MZ05A | |
| MID PIPE | TI | TB6100-MZ05A | |||
| MITSUBISHI | EVO7-9 JDM BUMPER | MUFFLER | TI | SINGLE | TB6090-MT01A |
| EVO8-9 USDM BUMPER | MUFFLER | TI | SINGLE | TB6090-MT01B | |
| EVO4-9 | EX-MANIFOLD | SUS | TB6010-MT01A | ||
| EVO7-9 | OUTLET COMPONENT | SUS | TB6060-MT01A | ||
| MID PIPE | TI | TB6100-MT01A | |||
| EVO10 | MUFFLER | TI | SINGLE | TB6090-MT02A | |
| OUTLET COMPONENT | SUS | TB6060-MT02A | |||
| MID PIPE | TI | TB6100-MT02A | |||
| FORD | 2015+ MUSTANG ECOBOOST |
MUFFLER | TI | SINGLE | TB6090-FR01A |
| BUMPER COVER | CARBON | PREMIUM | TE301A-FR01A | ||
| TE301A-FR01B | |||||
| FOCUS ST | MUFFLER | TI | SINGLE | TB6090-FR02A | |
| HYUNDAI | GENESIS COUPE 2.0T |
MUFFLER | TI | SINGLE | TB6090-HY01A |
| MID PIPE | TI | TB6100-HY01A | |||
| BUMPER COVER | CARBON | TE301A-HY01A |
